What is SS400 steel?

SS400 steel is a structural hot Rolled steel in the form of plates, sheets & strips for general structural applications. SS400 is a material grade and designation defined in JIS G 3101 standard. JIS G 3101 is a Japanese material standard for hot Rolled steel plates, sheets, strips for general structural usage.

What is the ASTM equivalent of SS400?

The DN equivalent for JIS SS400 is 17100 St 44-2; the ASTM equivalents are ASTM A36 and ASTM A283 Grade D; and the EN equivalents are EN S275 and BS 43A. Material Grades states that SS400 steel has a more reliable tensile strength than SS330 steel. The thickness of SS400 steel is between 6 and 20 millimeters.

What is the minimum percentage of elongation in SS400 steel?

The minimum percentage ranges for elongation is 17% thicknesses till 16 mm, 21% for thicknesses till 40 mm, and 23% greater than 50 mm. SPHC steel comparison with this grade of SS400 material will show how general structure hot rolled steel differs with commercial quality SPHC steel in chemical composition & mechanical properties.

What is the meaning of SS400 41?

SS41 Meaning: 41 means that the tensile strength is 41kgf/mm2 or higher. The following table shows the SS400 material specification and datasheet, including chemical composition, mechanical properties, physical properties and equivalent, etc.

Is SS400 same as A36?

First of all Xinsteel Industrial’s engineers confirm this answer is YES.

Is SS400 mild steel?

Mild Steel Ss400 Cr Plates is a kind of steel for general structure, and it is used in ship, house, bridge making and so on. This kind of steel plate sheet SS400 has some features like its heat condition, excellent freezing, even structure with pressure resistance and its good mechanical properties.

Is SS400 a low carbon steel?

Its use covers structures such as bridges, ships, vehicles, etc., in the shape of steel plates, steel bars and sections, almost all auxiliary materials for machinery and structures are used. SS400 is also soft in hardness due to its low carbon content.

Is SS400 stainless steel?

The 400 series group of stainless steels has an 11 percent chromium and 1-percent manganese increase, above the 300 series group. The 400 series is susceptible to rust and corrosion under some conditions. Heat-treating will harden the 400 series.

What is mild steel?

Mild steel is a ferrous metal made from iron and carbon. It is a low-priced material with properties that are suitable for most general engineering applications. Low carbon mild steel has good magnetic properties due to its high iron content, it is therefore defined as being ‘ferromagnetic’.

What is SUS304 material?

SUS304 (Japanese JIS Standard) is one of the most widely used versions of stainless steel. It is made up of 18% Cr (Chromium) and 8% Ni (Nickel). In high and low temperatures, it can maintain its strength and heat resistance.

What is grade A36?

A36 is a low carbon steel. Low carbon steels are classified by having less than 0.3% carbon by weight. This allows A36 steel to be easily machined, welded, and formed, making it extremely useful as a general-purpose steel. The low carbon also prevents heat treatment from having much of an effect on A36 steel.

What is JIS SS400?

SS400 Carbon Steel Pipe JIS G3101 SS400 is one of the most common carbon structural steel grade, other grades of JIS G3101 are ss330, ss490, ss540. Related product type includes steel plate, steel sheet, steel sections, steel pipes, etc.

Is 2062 structural steel?

IS2062 is a product standard of Bureau of Indian Standards for steel. It specifies standards for Hot Rolled Medium and High Tensile Structural Steel. These steels are used for structural purpose. We manufacture Round Bars conforming to IS2062 Grade E250A from sizes 25mm to 80mm.

What is 400 series stainless steel used for?

The 400 series of stainless steels have a higher carbon content, giving it a martensitic crystalline structure that provides the end product with high-strength and high-wear resistance. The 400 series steels tend to be used in agricultural equipment, gas turbine exhaust silencers, hardware, motor shafts, and more.

What’s the difference between 304 and 400 stainless steel?

300 and 400 series have comparable tensile strength and yield strength. 300 Series grades are highly ductile. On the contrary, 400 series grade has higher carbon content, tend to have more hardness than 300 series. Grade 400 series grades are stronger.

Is all 400 series stainless magnetic?

The 300-series stainless steels have varying degrees of nickel making them mostly non-magnetic. Devoid of nickel and with a grain structure similar to carbon steel, the 400-series stainless steels are slightly magnetic.

What is JIS SS400?

SS400 Carbon Steel Pipe JIS G3101 SS400 is one of the most common carbon structural steel grade, other grades of JIS G3101 are ss330, ss490, ss540. Related product type includes steel plate, steel sheet, steel sections, steel pipes, etc.

What is grade A36?

A36 is a low carbon steel. Low carbon steels are classified by having less than 0.3% carbon by weight. This allows A36 steel to be easily machined, welded, and formed, making it extremely useful as a general-purpose steel. The low carbon also prevents heat treatment from having much of an effect on A36 steel.

What is ss400p?

SS400steel plate sheet is a kind of steel for general structure,and it is used in ship,house,bridge making and so on. This kind of steel plate sheet SS400 has some features,like its heat condition,excellent freezing,even structure with pressure resistance and its good mechanical properties.

What is SPCC material?

Cold Rolled Carbon Steel Sheets and Strip (SPCC) is a Japanese industrial standard for cold rolled steel.

What is SS400 steel?

SS400 steel is a structural hot Rolled steel in the form of plates, sheets & strips for general structural applications. SS400 is a material grade and designation defined in JIS G 3101 standard.

What is the thickness of SS400 steel?

Dimensional Characteristics of SS400 Steels: The applicable thickness for this SS400 material as defined in the JIS 3101 starts from 6 mm to 120 mm.

What is the elongation of SS400 steel?

The elongation property of SS400 steel varies with the ranges of thickness. The minimum percentage ranges for elongation is 17% thicknesses till 16 mm, 21% for thicknesses till 40 mm, and 23% greater than 50 mm.

What is the maximum tensile strength of SS400 steel?

The tensile strength of the SS400 Steels is expressed in Newton per millimeters and it must be at least 400 N/mm2 (MPa) and the maximum can be 510 N/mm2 (MPa).
