Battery ag10 equivalent

What is the size of an Ag10 battery?

These batteries are also known as 189, AG10 or V10GA batteries. This LR54 battery measures 11.6mm in diameter and 3.1mm in height with 44-68mAh capacity. Is AG10 the same as LR1130? LR1130 is same as LR54 or AG10. L means it is an alkaline battery, R means it is round, 11 means it us 11.8mm in diameter and 30 means it is 3.0mm in height

What is the difference between an lr1130 and an Ag10 battery?

LR1130/AG10 batteries are alkaline 11.6 x 3.1 mm coin-cell batteries. The AG10’s alkaline chemistry is similar to that of a non-rechargeable primary cell. It works by causing a reaction between the two electrodes of the cell: zinc and manganese dioxide (MnO2). The AG10 is used for small electronic devices.

How many Ag10 batteries are in a blister pack?

Includes 10 AG10 batteries in a convenient blister pack for storage. These batteries ship free from the United States. Use our batteries to power your small electronics, lights, and toys. With 10 batteries per pack you’ll have extra to keep around.

Are Ag10 batteries safe for kids?

The AG10 is a compact and portable battery. Children under the age of three are at risk of choking from these alkaline batteries. As a result, make every effort to retain the ones you haven’t used in their original blister pack. Also, keep them out of reach of little kids.

Is LR44 same as AG10?

Despite the fact that they have the same diameter, AG10 is thinner (about 3.1 mm vs. about 5.4 mm for the LR44. As a result, the LR44 has slightly more capacity than the AG10.

Is an AG10 battery the same as an LR54?

An AG10 battery is the same as an LR54 battery. The LR54/AG10 battery is a high-performance alkaline button cell. The AG10/LR54 is an alkaline button cell battery that is used in small electronic devices such as calculators and electronic games. 1.5V is the voltage.

Is AG10 the same as LR1130?

Direct replacements for LR1130 would be 1130, AG10, 189, LR54, and LR55. These batteries are exact equivalents for the LR1130 battery, the only difference being the name.

Is AG10 same as 389?

389 Battery is a direct replacement for SR1130W, SR54, SR1130, SB-BU, 280-15, M, V389, D389, 626, S1131E, GP389, AG10, AG-10, 389, 189, L1131, G10, V10GA, LR1130, GP189, LR54, SG10, A389, L1131, L1131C, L1131D RW89.

Can I use AG13 instead of AG10?

No, their diameters are the same, but AG10 is thinner (about 3.1 mm vs. about 5.4 mm for the AG13). As a result, the AG13 has somewhat more than double the capacity of the AG10.

How long do AG10 batteries last?

three yearsAlkaline Button AG10 Batteries Have a Long Lifespan If stored at the right temperature, they can last for up to three years in storage. After which, they’ll still provide the same power output when you use them.

What is LR1130 compatible?

As with all similar batteries, the LR1130 battery’s capacity depends on the current drain and actual cutoff voltage of the powered device. Other most common labels used for alkaline 11.6 x 3.1 mm batteries are LR1131 (IEC standard), AG10, LR54, alkaline 189, alkaline 387, alkaline 389, alkaline 390, etc.

Is LR1130 the same as 390 389?

In this case, the silver oxide 389/390 (SR1130) is a longer lasting and more stable version of the alkaline (LR1130).

Can you interchange button batteries?

The nominal voltage of primary cells is 1.5V regardless if they are carbon-zinc or alkaline batteries. Carbon-zinc and alkaline batteries are thus interchangeable, just note that alkaline batteries have larger capacity and are generally more used than zinc-carbon batteries.

What battery is the same as 389?

Energizer 390-389 battery equivalent: 280-24, 390, 603, D390, GS10, S24, SB-AU, SR1130, SR1130SW, SRI-BOSW, TR1130W, V390, WS-10 1138SO, SR54, D389, SP389, SR1130W, V389, 1159SO, D390, 390, SP390, SR1130SW, V390, 189, 1168A, LR54, D189A, 189-1, LR1130, V10GA, GP89A, L1131, V390, 534, 390, 603, SB-AU, 280-24, GP390, …

Is LR1130 the same as L1131?

The normal thickness is 3.05mm and can be rounded up or down to 3.0 or 3.1 for part numbering reasons. Hence some manufacturers round up and some down. So we have the LR1130 L1130 and LR1131 L1131, both of which are the same battery.

What is LR54 battery equivalent?

The 189 (LR54) alkaline button cell battery is ideal for watches, calculators, photography, memory backup and other electronic devices. Battery equivalent to: SR1130W, SR54, AG10, SB-BU, G10, 280-15, GP189, M, V389, D389, 626, S1131E, V10GA, LR55, GP389, LR1130, 389, 189 and LR54.

What is an AG10?

What battery is equivalent to 389?

What is comparable to LR44 battery?

Direct replacements for LR44 would be Duracell 76A, Energizer A76, and AG13 batteries. These batteries are exact equivalents for the LR44 battery, the only difference being the name.

AG10 Battery Equivalents and Guide

AG10 batteries are small, non-rechargeable button/coin batteries. AG10 Batteries power devices like watch batteries, calculators, toys, and car keys. Equivalent AG10 batteries include LR54, LR1130, L1131, and G10. Many brands sell LR1130/AG10 batteries, but many label them differently, so users wonder which battery is an LR1130/AG10.

Features and Specifications of AG10 Batteries

A 1.5V/0.9V/45-70mAh alkaline battery, the AG10/LR1130 has a nominal voltage of 1.5V, a cutoff voltage of 0.9V, and a little capacity of 45-70mAh. A battery’s actual capacity varies with its age, operating temperature, and current drain.

A guide to the AG10, 1.5V alkaline button battery

It is a primary alkaline cell with non-rechargeable chemistry. The two electrodes of the cell: zinc and manganese dioxide (MnO2), work together to generate the current. A metal salt known as potassium hydroxide makes up the electrolyte.

AG10 Zinc-Air PR43 battery replacements with 11.6 x 3.1 mm

With zinc-air batteries, the electrolyte is moist/wet, and oxygen is drawn from the air. As a result, zinc Air batteries operate at a slightly lower voltage (*1.4 volts), have a more stable output, and generally have a greater capacity than alkaline batteries.

Final Words

You should purchase cheap, reputable brands that sell LR1130/AG10 batteries that have already been tried and tested by thousands of users if you need a non-rechargeable 11.6 x 3.1 mm coin-cell battery.
