AG Alkaline Batteries
| Code | Equivalent for Batteries |
| AG1 | SR621SW, SR60, SR621, SB-AG/DG, 280-34, … |
| AG2 | SR726SW, SR59, SR726, SB-AL, 280-28, N, … |
| AG3 | SR41W, SR736, SB-B1, 280-13, K, V392, D3 … |
| AG4 | SR626SW, SR66, SR626, SB-AW, 280-39, BA, … |
Aug 11 2022
| Alkaline | Low Drain Silver Oxide | |
|---|---|---|
| AG1 | 164 | SR621W |
| AG2 | 196 | SR726W |
| AG3 | 192 | SR41W |
| AG4 | 177 | SR626W |
What is the size of the Ag1 battery?
The AG1 battery is the alkaline version of this button battery. It has a diameter of 6.8mm and a height of 2.1mm and a nominal voltage of 1.5V. Other alkaline names include LR621 and LR60.
What is the difference between the Ag1 and SR60 battery?
The AG1 battery is the alkaline version of this button battery. It has a diameter of 6.8mm and a height of 2.1mm and a nominal voltage of 1.5V. Other alkaline names include LR621 and LR60. The silver oxide version has the exact same dimensions but is referred to as SR60, SR621SW, SR621 or number 364 watch battery.
What is the nominal voltage of an alkaline AG1?
164, 364, CX60, D364, E364, GP364, S621E, SA621SW, SB-DG, SB-AG, SG1, SP364, SR60, SR60L, SR620SW, SR621, SR621SW, SR621W, V364, V531, W1V, 364A, 364B Alkaline AG1 nominal voltage is 1.5 volts but through use the voltage drops quickly.
What batteries are equivalent to a silver oxide watch battery?
The silver oxide version has the exact same dimensions but is referred to as SR60, SR621SW, SR621 or number 364 watch battery. Below we have curated a list of equivalent batteries which are interchangeable. The alkaline batteries are not suitable for watch batteries even though they are much cheaper you should opt for silver oxide.
Is an AG1 battery the same as a 364?
Description. The Energizer 364/363 Watch Battery is a silver oxide replacement for the common watch battery sizes of 364, 363, AG1 and SR621SW. As the double numbered name suggests, this button cell battery is perfectly suited to both high drain and low drain applications and will work in watches requiring either.
Is a 377 watch battery the same as a 364?
Can I use a 364 battery instead of 377? 364 battery feature physical dimensions of 6.8 x 2.1 mm (lust as SR621SW battery) and it is generally not compatible with 377 battery with physical dimensions of 6.8 x 2.6 mm.
What is the equivalent of an LR60 battery?
The GP 164 alkaline battery is also known as LR60, LR620 and is manufactured by GP Batteries. The 164 battery is an alkaline 1.5 Volt battery and is very popular for use in watches and other small electronic devices.
What is equivalent to SR621?
Energizer 364-363 battery equivalent:SR621SW, Duracell D364, Bulova -602, Seiko SB-AG, citizen – 280-34, GP364, IEC SR601175SO, 164, 280-34, 362, 364, 364BP, 531, 602, AG1, D 364, D364, GP364, L621, LR60, LR620, LR621, R 364/31, RW 320, S621S, SB-AG/DG, SG1, SP364, SR 60, SR 621 SW, SR60, SR60L, SR621, T and V364.
What battery can replace 377?
377 Battery is a direct replacement for SR626SW, SR66, SR626, SB-AW, 280-39, BA, V377, D377, 606, S626E, GP377, AG4, AG-4, 377, L626, SG4, LR626, LR66, SR628SW, E377, E377CA, LR626SW, 377A, SR262SW, 377X, 377S, GP177, SR6265W, 377/376, E377A, SR66SW, SR625SW, 377BA, CR626SW, AG4/377, AG04 batteries.
Is Energizer 377 the same as LR44?
Direct replacements for LR44 would be Duracell 76A, Energizer A76, and AG13 batteries. These batteries are exact equivalents for the LR44 battery, the only difference being the name. These batteries can all be interchanged….LR44 Battery Nominal Voltage1.50 VoltsLR44 Battery Diameter11.6mmLR44 Battery Height5.4mm3 more rows
Which AG battery is equivalent to CR2032?
For as long as either fits in the battery compartment, the CR2025 and CR2032 may be used interchangeably with minimal effect although the CR2032 would probably last slightly longer simply because it has a higher capacity (mAh). 3.
What AG battery is equivalent to CR1220?
In most situations BR1220 and CR1220 batteries are interchangeable.
Can I use LR43 instead of SR43?
LR43 can be utilized in many devices such as watches, electronic toys, remote controls, and calculators. LR43 battery equivalents are also reffered to as SR43, AG12, LR1142, 386, 301, 186.
What is the difference between SR626SW and SR621SW?
SR626SW has a higher nominal capacity than SR621SW. The SR621SW has a nominal capacity of 23mAh, whereas the SR626SW has a nominal capacity of 28mAh, implying that the SR621SW can deliver more amps per hour and last longer than the SR626SW. Furthermore, the heights of SR621SW and SR626SW differ.
What is an LR41 battery equivalent to?
Direct replacements for LR41 would be 192, 92A,LR736, and AG3. These batteries are exact equivalents for the LR41 battery, the only difference being the name.
What is AG4 battery equivalent to?
AG4, LR626 and LR66 are alkaline button batteries with identical dimensions and specs. They are a very common button battery used for consumer electronics and are not rechargeable. The silver oxide equivalent is the SR626SW and SR626. Most typical use of an AG4 battery is as a wrist watch replacement battery.
What are 377 batteries used for?
Energizer Silver Oxide 1.5 Volt Button Battery 377 / 376 for watches toys, glucose monitors and calculators. The most used button cell for Accurist, Casio, Fossil, Seiko and Timex watches.
Is SR621SW the same as 364?
364 Battery is a direct replacement for SR621SW, SR60, SR621, SB-AG/DG, 280-34, T, V364, D364, 602, S621E, GP364, AG1, AG-1, 364, L621, LR621, SG1, LR60, LR620, SW621, GP164, 364X, 364A, AG1/364A, SB-AG, E364 batteries.
Will a 377 battery replace a 376?
Energizer 377-376 battery equivalent: Duracell 377, Duracell D377, Energizer 377, Maxell SR626SW, Panasonic SP377, Renata 377, Sony SR626SW, Timex BA, Toshiba SR626SW and Varta V377….Energizer 377-376 Battery Specs.Brand:EnergizerEnergizer 377-376 Battery Diameter:6.80 mmEnergizer 377-376 Battery Voltage:1.55V3 more rows
Is SR626SW battery the same as 377?
377 Battery is a direct replacement for SR626SW, SR66, SR626, SB-AW, 280-39, BA, V377, D377, 606, S626E, GP377, AG4, AG-4, 377, L626, SG4, LR626, LR66, SR628SW, E377, E377CA, LR626SW, 377A, SR262SW, 377X, 377S, GP177, SR6265W, 377/376, E377A, SR66SW, SR625SW, 377BA, CR626SW, AG4/377, AG04 batteries.
What is the size of an AG1 battery?
The AG1 battery is the alkaline version of this button battery. It has a diameter of 6.8mm and a height of 2.1mm and a nominal voltage of 1.5V. Other alkaline names include LR621 and LR60. The silver oxide version has the exact same dimensions but is referred to as SR60, SR621SW, SR621 or number 364 watch battery. Below we have curated a list of equivalent batteries which are interchangeable. The alkaline batteries are not suitable for watch batteries even though they are much cheaper you should opt for silver oxide.
What is the cut off voltage of a button battery?
The cut off voltage is 0.9 volts. Some devices have their own cut off voltage and could be 1 or 1.2V. With a average capacity of 12-15mAh these alkaline button batteries are mostly used for small electronics that require very tiny amounts of power and where constant voltage is not important.
What is an AG1 battery?
About the AG1 Battery. The AG1 is a 1.5 volt alkaline button cell battery. It is used in small electronics such as blinky lights and toys. AG1 is a common name and is identical to a LR60 battery. The AG prefix stands for the alkaline chemistry of the battery. It has a 6.8mm diameter and a 2.1mm height.
What are the names of the batteries used in Duracell?
General common names: SG1, LR60, LR821, and SR621, SR621SW are common compatible batteries. Brand names: Energizer and Duracell will use names of 164, 364.
What is the capacity of a silver oxide battery?
Silver oxide batteries will last longer as their capacity is about 20 mAh, 53% more. Most electronics can use both generic alkaline AG1 batteries or SR621SW silver oxide batteries.
What is the smallest button cell battery?
AG1 is the smallest alkaline button cell battery. These batteries ship free from the United States. With 10 batteries per pack you’ll have extra to keep around. Don’t get stuck without button batteries when you most need them. Save money off big name brands plus get more! In stock.
Can you use silver oxide batteries as a substitute for alkaline batteries?
Silver oxide batteries can be substituted for any alkaline battery because the size is the same. Using alkaline batteries to substitute silver oxide batteries works most of the time depending on the device. You may experience shorter battery life using alkaline cells in certain cases if the device requires a high voltage to operate.
377 Watch Battery and Equivalent Chart
Our 377 battery chart below shows all the equivalent battery models from different manufactures.
Where to buy a 377 battery or equivalent?
Most online stores will stock the 377 battery, we recommend Amazon, Ebay or Walmart
Best 377 Battery Brands
We recommend Energizer 377 silver oxide batteries. We do not advise buying any cheap brands from Amazon – they are Chinese made imports with no comeback for guarantee.
